Quality
of Image Prints
Optimal
quality of image prints can be achieved, when, for a chosen print size, the
printed image has the minimum required base image resolution, and the printing
resolution of the printer is adequate.
Definitions
of the related parameters, and the required values of these parameters, are
presented and discussed below.
ppi (pixels
per inch)
ppi is the number of pixels in each inch of the image, horizontally and
vertically, at the current printing size of the image.
For example, 360 ppi can be understood in two dimensions as 360 x 360 pixels
per square inch.
dpi (dots per inch)
dpi is the number of droplets of ink sprayed per inch of the image in
one particular direction during the printing process. Frequently, the
horizontal resolution and vertical resolution of the image print are not equal.
In high quality photographic printing, the common resolutions are 1440 dpi
horizontally, and 720 dpi vertically. This means that in a square inch, the
image is 1440 dots wide and 720 dots tall.
dpi is
limited by the type of printer to be used for printing the image.
In high quality photographic printing, dpi is always going to be a larger
number than ppi.
Base
Image Resolution (determined by the value of ppi)
Base
Image Resolution is the image’s resolution before it is artificially increased
(interpolated).
For high-quality image prints, required minimum value of the base image
resolution depends on the print size. Optimal minimum value of the base image
resolution is a function of the print size. Smaller prints will be viewed from
a closer distance, and, therefore, will require greater image resolution,
larger prints will most often be viewed from a greater distance, and,
therefore, will require lower image resolution..
Table
1 shows, for common print formats, the (subjective) acceptable minimum
base image resolutions (MBIR), and the minimum required sizes
of the corresponding digital images.
Table
1
Print Format
|
Common Usage
|
MBIR
|
Digital Image Size
|
Name
|
Size (width x height)
|
ppi
|
pixels
|
A6 (ISO-216)
|
105 mm x 148 mm
|
4.13” x 5.83”
|
books, postcards
|
360
|
1487 x 2099 ≈ 3.12 x 106
|
A5 (ISO-216)
|
148 mm x 210 mm
|
5.83” x 8.27”
|
books
|
300
|
1749 x 2481 ≈ 4.34 x 106
|
A4 (ISO-216)
|
210 mm x 297 mm
|
8.27” x 11.70”
|
letters, magazines, catalogues
|
240
|
1985 x 2808 ≈ 5.57 x 106
|
A3 (ISO-216)
|
297 mm x 420 mm
|
11.70” x 16.54”
|
posters, newspapers
|
200
|
2340 x 3308 ≈ 7.74 x 106
|
A2 (ISO-216)
|
420 mm x 594 mm
|
16.54” x 23.40”
|
posters
|
180
|
2977 x 4212 ≈ 12.54 x 106
|
A1 (ISO-216)
|
594 mm x 841 mm
|
23.40” x 33.11”
|
posters
|
160
|
3744 x 5298 ≈ 19.84 x 106
|
A0 (ISO-216)
|
841 mm x 1189 mm
|
33.11” x 46.81”
|
posters
|
140
|
4635 x 6553 ≈ 30.37 x 106
|
4R
|
102 mm x 152 mm
|
4” x 6”
|
photographs
|
360
|
1440 x 2160 ≈ 3.11 x 106
|
5R
|
127 mm x 178 mm
|
5” x 7"
|
photographs
|
300
|
1500 x 2100 ≈ 3.15 x 106
|
8R
|
203 mm x 254 mm
|
8” x 10"
|
photographs
|
240
|
1920 x 2400 ≈ 4.61 x 106
|
|
203 mm x 305 mm
|
8” x 12”
|
photographs
|
240
|
1920 x 2880 ≈ 4.67 x 106
|
ANSI – A ( ≈ A4 )
Letter
|
216 mm x 279 mm
|
8½” x 11”
|
posters
|
240
|
2040 x 2640 ≈ 5.39 x 106
|
Legal
|
216 mm x 356 mm
|
8½” x 14”
|
|
240
|
2040 x 3360 ≈ 6.85 x 106
|
14R
|
|
11” x 14"
|
photographs
|
200
|
2200 x 2800 ≈ 6.16 x 106
|
ANSI – B ( ≈ A3 )
Tabloid
|
279 mm x 432 mm
|
11” x 17”
|
posters
|
200
|
2200 x 3400 ≈ 7.48 x 106
|
|
305 mm x 457 mm
|
12” x 18”
|
|
200
|
2400 x 3600 ≈ 8.64 x 106
|
|
330 mm x 483 mm
|
13” x 19”
|
|
200
|
2600 x 3800 ≈ 9.88 x 106
|
|
406 mm x 508 mm
|
16” x 20"
|
|
180
|
2880 x 3600 ≈ 10.37 x 106
|
|
406 mm x 619 mm
|
16” x 24”
|
|
180
|
2880 x 4320 ≈ 12.44 x 106
|
ANSI – C ( ≈ A2 )
|
432 mm x 559 mm
|
17” x 22”
|
posters
|
180
|
3060 x 3960 ≈ 12.12 x 106
|
Broadsheet
|
457 mm x 610 mm
|
18” x 24”
|
posters
|
160
|
2880 x 3840 ≈ 11.06 x 106
|
|
508 mm x 610 mm
|
20” x 24"
|
|
140
|
2800 x 3360 ≈ 9.41 x 106
|
|
508 mm x 762 mm
|
20” x 30”
|
|
140
|
2800 x 4200 ≈ 11.76 x 106
|
ANSI – D ( ≈ A1 )
|
559 mm x 864 mm
|
22” x 34”
|
posters
|
140
|
3080 x 4760 ≈ 14.66 x 106
|
|
610 mm x 914 mm
|
24” x 36”
|
posters
|
140
|
3360 x 5040 ≈ 16.93 x 106
|
|
689 mm x 991 mm
|
27” x 39”
|
posters
|
140
|
3780 x 5460 ≈ 20.64 x 106
|
ANSI – E ( ≈ A0 )
|
864 mm x 1118 mm
|
34” x 44”
|
posters
|
140
|
4760 x 6160 ≈ 29.32 x 106
|
Table
2 shows, for common print formats, the minimum required sizes of the
corresponding digital images, when the value of the minimum base image resolution
(MBIR) is assumed to be equal 300 ppi.
Table
2
Print Format
|
Common Usage
|
Digital Image Size
|
Name
|
Size (width x height)
|
pixels
|
A6 (ISO-216)
|
105 mm x 148 mm
|
4.13” x 5.83”
|
books, postcards
|
1239 x 1749 ≈ 2.17 x 106
|
A5 (ISO-216)
|
148 mm x 210 mm
|
5.83” x 8.27”
|
books
|
1749 x 2481 ≈ 4.34 x 106
|
A4 (ISO-216)
|
210 mm x 297 mm
|
8.27” x 11.70”
|
letters, magazines, catalogues
|
2481 x 3510 ≈ 8.71 x 106
|
A3 (ISO-216)
|
297 mm x 420 mm
|
11.70” x 16.54”
|
posters, newspapers
|
3510 x 4962 ≈ 17.42 x 106
|
A2 (ISO-216)
|
420 mm x 594 mm
|
16.54” x 23.40”
|
posters
|
4962 x 7020 ≈ 34.83 x 106
|
A1 (ISO-216)
|
594 mm x 841 mm
|
23.40” x 33.11”
|
posters
|
7020 x 9933 ≈ 69.73 x 106
|
A0 (ISO-216)
|
841 mm x 1189 mm
|
33.11” x 46.81”
|
posters
|
9933 x 14043 ≈ 139.49 x 106
|
4R
|
102 mm x 152 mm
|
4” x 6”
|
photographs
|
1200 x 1800 ≈ 2.16 x 106
|
5R
|
127 mm x 178 mm
|
5” x 7"
|
photographs
|
1500 x 2100 ≈ 3.15 x 106
|
8R
|
203 mm x 254 mm
|
8” x 10"
|
photographs
|
2400 x 3000 ≈ 7.20 x 106
|
|
203 mm x 305 mm
|
8” x 12”
|
photographs
|
2400 x 3600 ≈ 8.64 x 106
|
ANSI – A ( ≈ A4 )
Letter
|
216 mm x 279 mm
|
8½” x 11”
|
posters
|
2550 x 3300 ≈ 8.42 x 106
|
Legal
|
216 mm x 356 mm
|
8½” x 14”
|
|
2550 x 4200 ≈ 10.71 x 106
|
14R
|
|
11” x 14"
|
photographs
|
3300 x 4200 ≈ 13.86 x 106
|
ANSI – B ( ≈ A3 )
Tabloid
|
279 mm x 432 mm
|
11” x 17”
|
posters
|
3300 x 5100 ≈ 16.83 x 106
|
|
305 mm x 457 mm
|
12” x 18”
|
|
3600 x 5400 ≈ 19.44 x 106
|
|
330 mm x 483 mm
|
13” x 19”
|
|
3900 x 5700 ≈ 22.23 x 106
|
|
406 mm x 508 mm
|
16” x 20"
|
|
4800 x 6000 ≈ 28.8 x 106
|
|
406 mm x 619 mm
|
16” x 24”
|
|
4800 x 7200 ≈ 34.56 x 106
|
ANSI – C ( ≈ A2 )
|
432 mm x 559 mm
|
17” x 22”
|
posters
|
5100 x 6600 ≈ 33.66 x 106
|
Broadsheet
|
457 mm x 610 mm
|
18” x 24”
|
posters
|
5400 x 7200 ≈ 38.88 x 106
|
|
508 mm x 610 mm
|
20” x 24"
|
|
6000 x 7200 ≈ 43.20 x 106
|
|
508 mm x 762 mm
|
20” x 30”
|
|
6000 x 9000 ≈ 54.00 x 106
|
ANSI – D ( ≈ A1 )
|
559 mm x 864 mm
|
22” x 34”
|
posters
|
6600 x 10200 ≈ 67.32 x 106
|
|
610 mm x 914 mm
|
24” x 36”
|
posters
|
7200 x 10800 ≈ 77.76 x 106
|
|
689 mm x 991 mm
|
27” x 39”
|
posters
|
8100 x 11700 ≈ 94.77 x 106
|
ANSI – E ( ≈ A0 )
|
864 mm x 1118 mm
|
34” x 44”
|
posters
|
10200 x 13200 ≈ 134.64 x 106
|
Printing Resolution (Output Resolution) (determined by the
value of dpi)
Printing Resolution is the number of droplets of ink sprayed per inch of
the image (dpi) in one particular direction, during the printing process. In
most cases, the horizontal printing resolution will be larger than the vertical
printing resolution
Assuming that the available inkjet printer has the maximum printing resolution 2880
dpi (horizontally) x 1440 dpi (vertically), one can determine the minimum
required (horizontal) printing resolution of the printed image, as a function
of the viewing distance of the observer from the print, which will satisfy the
observer.
Prints
which will be viewed from larger distance need smaller printing resolution.
A table of viewing distance versus the required minimum (horizontal) printing resolution
of the printed image which will satisfy the observer
Viewing Distance
|
Minimum (Horizontal)
Printing Resolution
|
3 ft. and closer
|
1440 dpi
|
6 ft. and closer
|
720 dpi
|
Farther than 6 ft.
|
360 dpi
|
Printing resolution of 2880 dpi (horizontally) is, in most cases, too high and
unnecessary. It is justified only if one would like to have exceptional shadow
details in the print. For reproducing a photograph with a base resolution of
around 300 ppi, in which one wants to see amazing details, the printing
resolution of 2880 dpi (horizontally) could be justified. For reproducing
artwork, the printing resolution of 1440 dpi (horizontally) is always adequate.
For printing a retail store poster,
which will not be scrutinized closely, the printing resolution of 720 dpi (or
even 360 dpi) (horizontally) is adequate.
Image Resizing
In practical terms, the size
of the original image can be increased up to four times, through interpolation,
if the original image has an acceptable base image resolution. In other words,
a good 8” x 10” image can look fairly good after increasing its size to 16” x
20”, through interpolation.
Resizing programs create
extra pixels from existing pixels, using some special mathematical
algorithms. Better known algorithms include: Nearest Neighbor Algorithm,
Bilinear Algorithm, Bicubic Algorithm, and Fractal Algorithms.
